B-01 DIN ISO -Standard Screw

Previous slide
Next slide

B01-01 ASME B18.6.3 SLOTTED HEX WASHER HEAD PHIL DRIVE BOLT

    • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
      CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-02 ISO7045 PAN HEAD SCREW WITH 6 LOBE DRIVE

  • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-03 PHIL DRIVE PAN HEAD SEMS SQUARE WASHER SCREW

  • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-04 DIN965 CROSS RECESSED COUNTERSUNK FLAT HEAD SCREW

  • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-05 PAN WASHER HAED SERRATED FLANGE SCREW

  • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-06 SLOTTED HEX WASHER HEAD TRIANGULAR THREAD BOLT

  • MATERIAL : C1022 + CASE HARDEN
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-07 PAN WASHER HAED SERRATED LOCK TRIANGULAR THREAD SCREW

  • PAN WASHER HAED SERRATED LOCK TRIANGULAR THREAD SCREW

B01-08 SQUARE SLOTTED ROUND WASHER HEAD SCREW

  • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-09 DIN931 HEX HEAD BOLT

  • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH

B01-10 PAN HEAD SCREW WITH POZI DRIVE

  • STRENGTH : ISO898-1 CLASS 4.8 ~ 12.9 OR ASME GRADE 5~10 OR A2-70 / A2-50
    CAPABILITY:M5~M10 METRIC OR 3/16~1/2 INCH
